BMA Specification

The Fleet Office hardware and software can ensure that your company meets the BMA Specification V:1.0 requirements for heavy & light vehicles.

Please contact us at [e-mail] to ensure your asset is on the correct IVMS script.

Click button to skip ahead to:

IVMS Trackers

The TFO IVMS (In-Vehicle Monitoring Systems) tracker is the required hardware.

Please see below the wiring requirements to meet BMA Specification standards:

Seat Belt	Input 1
4WD	Input 3 - If 4WD reporting is required a 6 wire IVMS will need to be installed.

Please contact our Hardware department for more information [e-mail] or call 1300 110 248

IVMS Driver Fob

Driver must sign on to IVMS using a Fob / iButton.  See article on how to Assign Fob to a User.

You will receive 1 x Fob with each IVMS, additional fobs are available for purchase.  Please contact [e-mail]

IVMS In Vehicle Alerts

As per BMA Specifications 2.1 4, the IVMS will activate an audible alarm if the driver exceeds the following parameters:

• Speeding
• Harsh Braking
• Harsh Acceleration
• Harsh Cornering
• Operation without Seatbelt
• Fatigue Management

This functionality is for the BMA provided Geofences.

Geofences

As per BMA Specifications 2.1 6, Geofences are uploaded by The Fleet Office team from files provided by BMA.  Please advise via [e-mail] which BMA sites are required.

The Geofences are non editable.

Alerts & Reports

How to create an Alert

How to create a Report

The following Alerts will need to be set up:

• Not Reported in 48 Hours
• Driver Behaviour. – This will capture tracker disconnections, harsh braking, harsh acceleration, harsh cornering, seatbelt, fatigue management & overspeed in reverse
• Speeding Alert 5km
• Speeding Alert 10km
• Speeding Alert 20km
• Possible Impact or Rollover
• Vehicle Duress

Reports

Upon the release of Report Wizard, there will be report options that mirror BMA required reports.  See Appendix 1 & 2 in BMA Spec V1:0

The Fleet Office will advise when Report Wizard is released.  In the meantime please build reports as listed below.

The following Reports will need to be created:

• Driver Behaviour Summary - Monthly Report
• Alerts Sent Out - Weekly Report

IVMS Event Codes

The following list shows all event codes for IVMS Trackers.

Codes	Reason
0	Breadcrumb Report
1	Ignition On
2	Ignition Off
8	4WD Engaged
9	4WD Disengaged
10	Forward Acceleration
11	Reverse Acceleration
12	Left Acceleration
13	Right Acceleration
14	Reverse Speeding
15	Tilt Detected
16	Tilt Detected - forward
17	Tilt Detected - lateral
20	Accident Detected
30	Fatigue Warning Issued
31	Fatigue Limit Reached
32	Fatigue Reportable Event
35	Driver Signed In
36	Driving Without Sign In
37	Sign In With an Unknown Device (server generated)
38	Rest Paused/Vehicle Moving/Driving Time Started
39	Rest Started/Vehicle Stationary (obsolete)
40	Driving Without a Seatbelt Start
41	Driving Without a Seatbelt End
53	Rest Started/Vehicle Stationary
91	A 15 Minute Break Has Been Taken
92	Fatigue Warning During Break
93	Fatigue Alarm During Break
95	Rest Button is Pressed (Rest Started)
96	Rest Button is Pressed (Rest Cancelled)
98	GPS Lost Report
99	Device Disconnected (battery low) Report
128	Clear Current Fatigue Alarm/Warning
129	Reset all Fatigue Timers
